Bosch 14 Place Setting Dishwasher - Fully Integrated with 6 Programs - Panel Ready (Series 4/SMV4HTX01A)

SMV4HTX01A
Bosch 14 Place Setting Dishwasher - Fully Integrated with 6 Programs - Panel Ready (Series 4/SMV4HTX01A)
Shortlist Compare
Free Delivery
$2,240

FREE DELIVERY!* Details

or 60 months of equal Gem Visa Interest Free Installments of
$37.33^
approximately
Total repayments $2,240 excluding fees.

This section should always be read in conjunction with the Terms and Conditions for Product CareTM.

Find in Store

For delivery estimate
& stock availability


Available on 60 months of equal Interest Free instalments:

$37.33^
approximately
per month
^ Total repayments $2,240 (excluding fees). Payment is required monthly. Min purchase applies. Offer ends 28/01/2025. Exclusions, T&Cs & fees apply incl. a $55 Gem Visa estb. fee & annual fees ($65 Gem Visa (charged $32.50 half yearly)/$65 Gem CreditLine (charged $32.50 half yearly)). Interest rate (currently Gem Visa 29.49% p.a./CreditLine 29.95% p.a.) applies after any interest free term ends. Credit provided by Latitude Financial Services Ltd. For cash advances, an interest rate of 29.95% p.a. and fees of $2 Gem Visa/$6 Gem CreditLine applies. Further information on rates and fees can be found at gemfinance.co.nz.
How it works
Description

  • Extended Range Item | Available by Special Order Only

    Delivery expectation: 2-4 weeks
    This item is available by special order and may not be stocked in stores. Purchase online today to secure your product. For more information, please contact your local Harvey Norman store.

FREE DELIVERY!*

Customise with your own door panel and handle to match your kitchen cabinetry.

Clean your dishes to perfection with the Bosch 14 Place Setting Dishwasher! A wonderful addition to your kitchen, this nifty appliance packs an array of advanced technologies in a sleek, modern build. It is also powered by EcoSilence Drive to wash your dinnerware efficiently and quietly. On top of that, it offers 6 wash programs, 5 special options, and a Rackmatic feature for optimum flexibility.

Key Overview

  • 14 Place Setting Capacity
  • Fully Integrated Dishwasher
  • Cold Water Supply Required
  • 4 Star Energy Star Rating
  • 4 Star Water Rating
  • 46 dB Noise Level
  • (H x W x D) - 815 x 598 x 555 mm
  • Kitchen Integration Required

Product Highlights

  • Exceptional Washing Performance: Cleaning your dishes is no longer a hassle with the Bosch 14 Place Setting Dishwasher! This appliance provides incredible cleaning results, packing various cutting-edge features like EcoSilence Drive, HygienePlus, DosageAssist, AutoBrilliance, Heat Exchanger, 5 Spray Levels, and 3-Stage Filter System.
  • Multiple Programs: To suit your different washing needs, this unit offers 6 handy programs—Eco Wash, Auto Wash, Pots & Pans, Quick 1hr, Glass Wash, and Favourite. It also has 5 special options for added convenience, such as Remote Start, Extra Dry, Hygiene Plus, and SpeedPerfect.
  • Convenient Operations: The Series 4 Dishwasher is easy to operate, thanks to its control buttons, program end indicator tone, time remaining display, InfoLight, Favourite function, and Extra Dry option. Moreover, it works with the Home Connect app for seamless controls via your smartphone.
  • Spacious Interior: With its 14-place setting, you can wash and organise more dinnerware in one go. For added flexibility, it also utilises the VarioFlex basket system, Rackmatic, foldable plate racks, foldable cup shelves, a moveable cutlery basket, and a knife and cutlery tray.
  • Minimalist Appearance: Achieve a sleek and uncluttered look in your kitchen, as this Bosch Dishwasher seamlessly integrates into your cabinetry. It also showcases a panel-ready design, allowing you to easily customise to blend well into your interior*.

*Please Note: This appliance requires a custom-made panel to be attached to its front to provide an integrated look with your kitchen cabinetry. This Dishwasher does not come with a door panel or handle to attach to the front.

Specifications
All Product Details
Brand Bosch
Product Type Fully Integrated Dishwasher
Model Number SMV4HTX01A
Colour Custom Panel Ready
Whiteware Capacity
Dishdrawer Capacity 14 Place Setting
Energy
Energy Star Rating 4 Star
Energy Consumption 230 kWh/year
Water Efficiency
Water Rating (WELS: Water Efficiency Labelling and Standards) 4 Star
Water Consumption 13.5 L per wash
Water Supply Cold Water Supply Required
Dishwasher Features
Dishwashing Option
  • AutoDos
  • Express
  • Extra Clean
  • Extra Dry
Number of Spray Arm 5
Dispensers Detergent and Rinse Aid Dispensers
Removable Worktop No
Dishwasher Feature
  • Adjustable Rack Height
  • Aqua Sensor Technology
  • Automatic Dispensing
  • Electronic Fault/Diagnostic Indicator
  • End-of-Cycle Signal
  • Fingerprint Resistant
  • Flood Protection
  • Flow Through Detergent Dispenser
  • Fold Down Tines
  • Foldable Cup Racks
  • Internal Wash Selector
  • Intuitive Capacitive Touch Controls
  • Kickstrip
  • Load Sensor Technology
  • Quiet Operation
  • Rinse Aid Indicator Light
  • Spray Arm Sensing
  • Time Delay Start
  • Time Remaining Display
  • Top Shower
  • Waterproof System
  • Wine Glass Supports
Rack / Basket Design
Number of Racks 2 x Racks
Upper Rack Feature Can be adjusted to various heights
Lower Rack Feature Spray Zone
Cutlery Basket Included
Cutlery Basket Feature Moveable Cutlery Basket
Drying
Drying Method Heat Exchanger
Temperature
Temperature Range (°C) 40 to 70 °C
Door Features
Default Door Hinge Bottom
Plumbed Water Supply Required Yes
Door Handle Type Customizable Door Handle (Not Included)
Door Design Customizable Door Panel (Not Included)
Door Lock Yes
Control Panel Features
Control Panel Type Integrated Button Controls
Location of Control Panel Integrated Top Inside Door Control
Motor
Type of Motor EcoSilence Drive BLDC Motor
Noise Level 46 dB
Cycle
Number of Wash Programs 6 x Wash Programs
Wash Programs Eco Wash, Auto Wash, Pots & Pans, Quick 1hr, Glass Wash, Favourite
Extras Programs Machine Care
Smart Features
Display Type Integrated Top Button Controls
Wi-Fi Embedded Yes
Connectivity Type Wi-Fi
Smart Diagnosis Yes
Smart Functions Remote monitoring and control, software update appliance, iservice remote
Software / App Compatibility
App Enabled Yes
Compatible App Home Connect App
Installation
Assembly Type Kitchen Integration Required
Installation Type Integrated - Qualified Plumber and Kitchen Integration Required
Plumbing Requirements Cold Water Supply Required
Electrical Connection
Type of Connection 10A Plug & Lead
Wattage/Voltage 220-240 V
Fuse Rating 10A
Dimensions
Height 815 mm
Width 598 mm
Depth 555 mm
Product Weight 35.9 kg
Warranty
Manufacturers 24 Months
Reviews
Bosch 14 Place Setting Dishwasher - Fully Integrated with 6 Programs - Panel Ready (Series 4/SMV4HTX01A) is rated 4.9 out of 5 by 30.
Rated 5 out of 5 by from Bosch Dishwasher [This review was collected as part of a promotion.] Very happy with my purchase. Full easy to read installation instructions were included. Template to install front door panel worked perfectly. Included hose holders as well to secure them. Easy to adjust height. Included parts were of a high quality including brackets and torx screws. Includes kick plate adjustable brackets. Downloaded app which made initial setup a breeze. Has fantastic adjustable baskets, with a spray nozzel for oversized items. Purchased due to low water usage and energy savings. Also qualifuies for QLD government energy savings appliance rebate.
Date published: 2023-11-19
Rated 5 out of 5 by from Bosch SMV4HTX01A Review [This review was collected as part of a promotion.] What a great product, was recomended by my dishwasher repair man. We had another company's dishwasher for about 12 years and was having lots of trouble leading up to when replacement the only option. So you go with the people that know and what a fantastic replacement it is. The Bosch dishwasher fitted the space in the cabinet with no further tradesmen needed. The Bosch is a far better product than the old one and we are so happy wiyh it. Many thanks Malcolm
Date published: 2023-11-06
Rated 5 out of 5 by from Bosch Series 4 fully-integrated Dishwasher Used dishwasher today after having it installed and extremely happy with the dishwasher, and all dishes ,cutlery ,glasses,cleaned and dried perfectly just like our previous Bosch Dishwasher did for last 10 years for us.Only reason we updated dishwasher was due to the fact motor was infested with rodents, and circuits ceased working.We were totally unaware insects had entered the dishwasher until it ceased working and we obtained a technician report. We had no hesitation in getting another Bosch Dishwasher, and we will to be sure our cabinet is sprayed annually for cockroaches etc.so this problem never occurs again, because I am convinced the old dishwaher would have lasted longer than 10 years, as we kept it clean and maintained it well.Definitely recommend only Bosch Dishwasher to anyone, there is no peer in our opinion.
Date published: 2023-01-27
Rated 5 out of 5 by from We love it!!! [This review was collected as part of a promotion.] This is our first Bosch appliance, and we couldn't be happier. It operates very quietly, it holds so many dishes and cutlery, and wether it is half full or a full load - all the dishes come out clean and dry. We absolutely recommend this dishwasher, and we'll be looking at other Bosch appliances in the future. We are SO happy!
Date published: 2023-10-28
Rated 5 out of 5 by from Solid and Quiet [This review was collected as part of a promotion.] I'm so impressed with this purchase, the Series 4 replaced our 12 month old Fisher and Paykal and I'm glad we made the switch. The Series 4 washes perfectly, it's quiet and it feels solid / well made. I didn't expect all of this when not purchasing the most current series model. Would buy again.
Date published: 2023-12-22
Rated 5 out of 5 by from Bosch dishwasher [This review was collected as part of a promotion.] Excellent dishwasher replaced my Delinghi can't believe how clean my dishes and cutlery are now mainly use the speed perfect wash no need for rinsing dishes first just scrap any food off then put them in the dishwasher with Finish tablet all come out perfect & dry even plastic containers
Date published: 2023-11-07
Rated 4 out of 5 by from Kitchen Reno [This review was collected as part of a promotion.] I have recently purchased this dishwasher as I was completing a kitchen renovation and wanted to incorporate a integrated dishwasher that wouldn't break the bank. Since using the dishwasher I have been impressed on how easy it is to use, the amount of space and how quiet it is.
Date published: 2024-01-22
Rated 5 out of 5 by from Works great and looks great! [This review was collected as part of a promotion.] We had our brand new fully integrated dishwasher installed with our new kitchen and it is just amazing. Cleans great and blends in seamlessly with our cabinetry. Also, I never knew a new dishwasher could smell like a new car, but apparently they can, win win!
Date published: 2024-03-22
  • y_2025, m_1, d_6, h_7
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.42
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_30
  • loc_en_NZ, sid_81850, prod, sort_[SortEntry(order=RELEVANCE, direction=DESCENDING)]
  • clientName_harvey-norman-en_nz
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getContent, 21.35ms
  • REVIEWS, PRODUCT
Delivery
Delivery

We aim to dispatch orders within 2 days. Delivery costs are calculated based on your location and the size of your order. Furniture may take up to 8 weeks to deliver as most products are made specifically for your order. Some Customer Direct products are shipped from overseas and may take longer to arrive. Some goods may take longer to deliver if a product is currently not in stock. A staff member will contact you where this occurs.

Easy returns

If you feel your product has failed a Consumer Guarantee (as defined by New Zealand Consumer Law) then don't worry you can easily return it to your local Harvey Norman store. We'll even pay for the postage if you live in an area where there is no store. Our returns policy covers any purchased item ( conditions apply).

What's in the box
  • 1 x Bosch 14 Place Setting Fully Integrated Dishwasher
  • 1 x Drain Hose
  • 1 x Large Items Spray Head
  • 1 x Vapor Barrier Plate
  • 1 x User Guide
